toy user manual

Title toy (Assembler and simulator for the Princeton TOY machine)

Nikolaos Kavvadias 2010, 2011, 2012, 2013, 2014

toy.c written by Christopher W. Fraser.

Release Date 02 December 2014
Version 0.0.3
Rev. history


Added project logo to README.



Updated for Github.



Initial release.

1. Introduction

toy is a collection of software development tools for the Princeton TOY processor. toyasm is a single-pass assembler and toy is the TOY simulator by Chris Fraser.

2. File listing

The toy distribution includes the following files:

/toy Top-level directory
AUTHORS List of toy authors.
LICENSE The modified BSD license governs toy.
Makefile Makefile for toy and toyasm.
README.html HTML version of README.
README.pdf PDF version of README.
README.rst This file.
VERSION Current version of the project sources.
fibo.asm TOY assembly implementation of Fibonacci's algorithm.
fibo.c Reference implementation of Fibonacci sequence generation in ANSI C.
fibo.toy TOY machine code file of fibo.asm for the toy simulator.
main.c Driver C file for the toyasm assembler.
popcount.asm TOY assembly implementation of population count.
popcount.c Reference implementation of population count in ANSI C.
popcount.toy TOY machine code file of popcount.asm for the toy simulator. Bash script for generating the HTML and PDF versions of the documentation (README).
toy.c The toy simulator.
toy.l Lexer for the TOY assembler.
toy.png PNG image for the toy project logo.
toy.y Parser for the TOY assembler.
toy-cheatsheet.txt TOY reference card

3. Usage

  1. Run make from the Cygwin/MinGW/Linux command line:
$ make clean
$ make
  1. Run a test for fibo:
$ ./toyasm[.exe] fibo.asm > fibo.toy
$ ./toy[.exe] fibo.toy

When prompted give a 16-bit hexadecimal constant (e.g. 0008) from stdin (the toy simulator features an interactive console). Then the simulator executes and prints 0015 (21 in decimal) as the correct result for the 8-th element of Fibonacci's sequence.

Similarly, you can run a test for popcount by entering a hexadecimal number; the TOY simulator console will then return the number of ones in that number.

4. Prerequisites

5. Contact

You may contact me at:

Nikolaos Kavvadias <>
Independent Consultant
Kornarou 12 Rd,
35100 Lamia, Fthiotis
