kdiv user manual

Title kdiv (Constant division routine generator)
Author Nikolaos Kavvadias



Website http://www.nkavvadias.com
Release Date 29 November 2014
Version 0.1.1
Rev. history


Added project logo in README.



Documentation updates and fixes.



Renamed README to README.rst.



Updated contact information. Replaced COPYING.BSD by LICENSE.



Converted documentation to RestructuredText.



Split build-and-test scripts to build and test.



Minor README updates regarding multiple releases, tutorial usage.



Minor README, Makefile updates.



Added omitted constant value for M in C routines.



Small fixes, avoids emitting redundant shift.



Initial release.

1. Introduction

kdiv is a generator for routines for optimized division by an integer constant. It can be used for calculating an integer division with the routines presented in Henry S. Warren's "Hacker's Delight" book. kdiv can also be used for emitting a NAC (generic assembly language) or ANSI C implementation of the division.

2. File listing

The kdiv distribution includes the following files:

/kdiv Top-level directory
LICENSE Description of the Modified BSD license.
Makefile Makefile for generating the kdiv executable.
README.html HTML version of README.rst.
README.pdf PDF version of README.rst.
README.rst This file.
build.sh Build script for kdiv.
kdiv.c The source code for the application.
kdiv.png PNG image for the kdiv project logo.
rst2docs.sh Bash script for generating the HTML and PDF versions.
test.c Sample test file.
test.opt.c Expected optimized version of test.c.
test.sh Perform some sample runs.

3. Installation

There exists a quite portable Makefile (Makefile in the current directory). Running make from the command prompt should compile kdiv.

4. Prerequisites

5. kdiv usage

The kdiv program can be invoked with several options (see complete option listing below). The usual tasks that can be accomplished with kdiv are:

ANSI C routines have been tested only for a width of 32-bits (see option below).

kdiv can be invoked as:

$./kdiv [options]

The complete kdiv options listing:

Print this help.
Enable debug/diagnostic output.
Report only inconsistencies to the expected division results.
-div <num>
Set the value of the divisor (an integer except zero). Default: 1.
-width <num>
Set the bitwidth of all operands: dividend, divisor and quotient. Default: 32.
-lo <num>
Set the lower integer bound for dividend testing. Debug output (-d) must be enabled. Default: 0.
-hi <num>
Set the higher integer bound for dividend testing. Debug output (-d) must be enabled. Default: 65535.
Construct optimized routine for signed division.
Construct optimized routine for unsigned division (default).
Emit software routine in the NAC general assembly language (default).
Emit software routine in ANSI C (only for width=32).

Here follow some simple usage examples of kdiv.

  1. Generate the ANSI C implementation of n/11 optimized routine.
$ ./kdiv -div 11 -width 32 -unsigned -ansic
  1. Generate the NAC implementation of n/(-7) optimized routine.
$ ./kdiv -div -7 -width 32 -signed -ansic

3. Generate the ANSI C implementation of n/23 optimized routine. Also run some tests with an internal generator for the dividend range [0..1024].

$ ./kdiv -div 23 -width 32 -unsigned -ansic -d -lo 0 -hi 1024

6. Quick tutorial

kdiv can be used for arithmetic optimizations in user programs. Assume the following user program (test.c):

// test.c
#include <stdio.h>
#include <stdlib.h>
int main(int argc, char *argv[]) {
  int a, b;
  a = atoi(argv[1]);
  b = a / 23;
  printf("b = %d\n", b);
  return b;

This file is compiled and run as follows with one additional argument:

$ gcc -Wall -O2 -o test.exe test.c
$ ./test.exe 155

and the expected result is:

$ b = 6

The user can apply kdiv for generating a constant division routine for a/23:

$ ./kdiv -div 23 -width 32 -signed -ansic

and the corresponding routine is produced. Then, the user should edit a new file, let's say test.opt.c and include the produced routine. The resulting optimized source file should be as follows:

// test.opt.c
#include <stdio.h>
#include <stdlib.h>
inline signed int kdiv_s32_p_23 (signed int n)
  signed int q, M=-1307163959, c;
  signed long long int t, u, v;
  t = (signed long long int)M * (signed long long int)n;
  q = t >> 32;
  q = q + n;
  q = q >> 4;
  c = n >> 31;
  q = q + c;
  return (q);

int main(int argc, char *argv[]) {
  int a, b;
  a = atoi(argv[1]);
  b = kdiv_s32_p_23(a);
  printf("b = %d\n", b);
  return b;

This file is compiled and run as follows with one additional argument:

$ gcc -Wall -O2 -o test.opt.exe test.opt.c
$ ./test.opt.exe 155

The target platform compiler (e.g. gcc or llvm) is expected to inline the kdiv_s32_p_23 function at its call site.

7. Running tests

In order to build and run a series of sample tests do the following:

$ ./build.sh
$ ./test.sh

8. Contact

You may contact me for further questions/suggestions/corrections at:

Nikolaos Kavvadias <nikos@nkavvadias.com>
Independent Consultant
Lamia, Fthiotis, Greece
